Cisco C9300L-48UXG-4X-E
Catalyst 9300L 48p, 12mGig, Network Essentials ,4x10G Uplink
Product Highlights
What's Included
(1) PWR-C1-1100WAC-P
(1) AC Power Cord
(1) Rackmount Kit (RACK-KIT-T1)
Modern enterprise networks demand more from the access layer than ever before. Wi-Fi 6 access points, IP surveillance cameras, IoT sensors, and converged voice/video endpoints all require multi-gigabit speeds and substantial PoE power — and they need it at scale.
The Cisco C9300L-48UXG-4X-E is a Catalyst 9300L Series fixed-uplink switch purpose-built for these high-density, power-hungry environments. It delivers 48 UPOE copper ports — 12 of which support MultiGigabit speeds up to 10G, with the remaining 36 providing standard Gigabit Ethernet — alongside four fixed 10G SFP+ uplinks for high-bandwidth fiber connectivity to your distribution or core layer. Shipping with a 1100W AC power supply, it provides a default 675W PoE budget that can be expanded with a second power supply.
Running Cisco IOS XE with the Network Essentials license, the C9300L-48UXG-4X-E supports Layer 2 and Layer 3 forwarding, hardware-based ACLs, QoS, and integrated security features such as 802.1X, DHCP Snooping, and TrustSec. Optional StackWise-320 stacking enables up to eight C9300L switches to operate as a single logical device with up to 320 Gbps of stacking bandwidth, dramatically simplifying management and improving resiliency. As a foundational building block for Cisco Software-Defined Access (SD-Access), this switch helps IT teams transition to intent-based networking while protecting their existing infrastructure investment.
Features & Benefits
High-Density MultiGigabit UPOE Access
With 12 MultiGigabit ports supporting speeds from 100M up to 10G and 36 additional Gigabit Ethernet ports — all with Cisco UPOE — this switch delivers the bandwidth and power modern endpoints demand. Deploy Wi-Fi 6 APs, 4K IP cameras, and IoT devices without external power injectors, leveraging a default 675W PoE budget that scales to 1775W with a second power supply.
10G SFP+ Uplinks
Four fixed 10G SFP+ uplink ports provide high-speed fiber connectivity to your distribution or core switches. This ensures the access layer doesn't become a bottleneck, even under heavy traffic loads from bandwidth-intensive applications like video conferencing and cloud workloads.
StackWise-320 Stacking
Using the optional C9300L-STACK-KIT, up to eight C9300L switches can be stacked with up to 320 Gbps of stacking bandwidth. The stack operates as a single logical device with a unified management and control plane, simplifying operations and providing high availability with non-stop forwarding during maintenance events.
Cisco IOS XE & Network Essentials License
The Network Essentials license includes Layer 2 and Layer 3 switching capabilities such as static routing and RIP, hardware-based ACLs, and QoS. Built-in security features — including 802.1X authentication, DHCP Snooping, Dynamic ARP Inspection, and Cisco TrustSec — enforce access control and mitigate threats at the network edge.
SD-Access Ready
As part of the Cisco Catalyst 9000 family, the C9300L-48UXG-4X-E serves as a foundational building block for Cisco Software-Defined Access (SD-Access). This enables intent-based networking, automated policy enforcement, and end-to-end segmentation managed through Cisco DNA Center.
Deployment Scenarios
Enterprise Campus Access Layer
Deploy at the campus edge to connect desktops, VoIP phones, printers, and wireless access points. The 48 UPOE ports eliminate the need for separate power injectors, while 12 mGig ports provide the bandwidth headroom that Wi-Fi 6 APs and high-performance workstations require.
Wi-Fi 6 / Wi-Fi 6E AP Aggregation
MultiGigabit ports deliver 2.5G, 5G, or 10G backhaul to next-generation wireless access points, ensuring the wired infrastructure doesn't bottleneck wireless throughput. UPOE provides up to 60W per port to power the latest APs without external injectors.
Converged IoT & IP Surveillance
Support high-density IoT sensor networks and IP camera deployments with UPOE power and Gigabit/MultiGigabit connectivity. Cisco TrustSec and hardware-based ACLs provide segmentation and security for diverse endpoint types sharing the same physical infrastructure.
Branch Office Distribution
Stack multiple C9300L switches via StackWise-320 to create a resilient, centrally managed switching fabric for medium-to-large branch offices. The 4x10G SFP+ uplinks provide high-speed WAN or data center connectivity, while the Network Essentials license covers essential Layer 3 routing needs.
General
Ports & Interfaces
Performance
Power
Stacking
Physical
Environmental
Compatibility Notes
Stacking: Requires the optional C9300L-STACK-KIT (two stack adapters + one stacking cable). Compatible stacking cables: STACK-T3-50CM (default), STACK-T3-1M, STACK-T3-3M. C9300L models can only stack with other C9300L models — they cannot be stacked with modular uplink C9300/C9300X SKUs or older Catalyst 3850/3650 Series switches.
Power Supplies: Ships with one PWR-C1-1100WAC-P. The switch has two PSU slots; a second power supply can be added for redundancy and expanded PoE budget. Compatible PSU options: PWR-C1-350WAC-P, PWR-C1-715WAC-P, PWR-C1-1100WAC-P.
Optics (Uplinks): The 4x 10G SFP+ uplink slots accept Cisco 10G SFP+ transceivers (e.g., SFP-10G-SR, SFP-10G-LR, SFP-10G-LRM, SFP-H10GB-CU1M/3M/5M).
Software: Runs Cisco IOS XE. Network Essentials license is included.
Downloads & Resources
Frequently Asked Questions
| Part Number | Product | Key Difference |
|---|---|---|
| C9300L-48UXG-4X-A | Catalyst 9300L 48p mGig, Network Advantage, 4x10G | Same hardware with Network Advantage license — adds OSPF, BGP, EIGRP, PBR, VRF-Lite, and VXLAN for advanced Layer 3 routing. |
| C9300L-48UXG-2Q-E | Catalyst 9300L 48p mGig, Network Essentials, 2x40G | Same access ports but with 2x 40G QSFP+ uplinks instead of 4x 10G SFP+ — ideal when higher uplink bandwidth is needed. |
| C9300L-24UXG-4X-E | Catalyst 9300L 24p mGig, Network Essentials, 4x10G | 24-port variant of the same platform — lower port density and PoE budget for smaller deployments. |
| C9300L-48PF-4G-E | Catalyst 9300L 48p PoE+, Network Essentials, 4x1G | 48-port PoE+ (no mGig or UPOE) with 4x 1G SFP uplinks — lower cost option when multi-gigabit speeds are not required. |
