Cisco PA-2T3/E3-EC

2 Port Clear Channel T3/E3 Enhanced Capability

In Stock
US $350.00
Add to cart Make offer
Product Highlights
Family
Modules
Brand
Cisco
Warranty
Lifetime (see details)
Availability
Usually Ships Same Day if Ordered by 1PM PST


Twitter Reddit Facebook

Information

This module is a single-width port adapter that provides two T3 interface connections using BNC connectors. The T3 link provides a single high-speed user data channel that appears to the system as a serial interface that may be configured to use the full T3 bandwidth or a smaller portion of the T3 bandwidth.

Specifications

Weight
2.5 lb
Dimensions
1 Height x 6.6 Width x 7 Depth
Management
  • MIB-II (RFC 1213)
  • MIB (RFC 1407)
Product Name
2-Port T3/E3 Port Adapter
Product Type
Port Adapter
Compatibility
  • Cisco 7200 VXR routers
  • Cisco 7301 routers
Interfaces/Ports
2 x T3/E3
Connectivity Media
Coaxial T3/E3
Data Transfer Rate
  • 34.368Mbps E3 Full-duplex
  • 44.736Mbps T3 Full-duplex
Interfaces Details
2 x BNC T3/E3
Additional Information
  • High-speed High-Level Data Link Control (HDLC) data
  • Integrated data service unit (DSU) functionality
  • Support for 16- and 32-bit cyclic redundancy checks (CRCs)
  • Support for G.751 framing or bypass framing
